L-6C CNC Lathe

Linear guideways, integral casting bed structure smaller footprint CNC Lathe
Swing over bed dia.φ440mm
Swing over saddleφ220mm
Max. turning dia.φ220mm
Max. turning length200mm
Turret typeServo V8
Drive typeBelt drive
Max. spindle speed6000rpm
Spindle motor power5.5/7.5kw
Spindle noseJISA2-5
Spindle through holeφ51mm
Chuck size6 inch
Bar capacity dia.φ41mm

L Series adopts an integral casting bed structure, optimize parameters and internal structure, has a smaller foot print,.

Configure high-precision and high rigidity roller guides, mechanical spindle and servo turret,ensure high precision, efficiency, and stability of machine tools.
